GERAL
Fonte: Bivolt
Consumo Máximo: 500 W
Dimensão (L x P x A): 43.1 x 34.4 x 8.3 cm
Peso: 9 kg
ENTRADAS ANALÓGICAS
Quantidade: 3
Signal/noise ratio (A-wtd, ref. 50W, 1V input): 106dB
Frequência de Resposta: 20Hz—20kHz ± 0.2dB
POTÊNCIA CONTÍNUA
2 channels driven, 20Hz - 20kHz, 8Ω 100W
2 channels driven, 1kHz, 4Ω 165W
Harmonic distortion, 80% power, 8 ohms at 1kHz 0.002%
ENTRADA PHONO
Impedância de Entrada: 47kOhms + 100pF
Frequência de Resposta (ref. RIAA curve) 20Hz—20kHz ± 1dB
ENTRADAS DIGITAIS
Sample Rates com Suporte (kHz):
USB-C 384, 352.8, 192, 176.4, 96, 88.2, 48, 44.1
Coaxial (RCA) 192, 176.4, 96, 88.2, 48, 44.1
Optical (Toslink) 192, 176.4, 96, 88.2, 48, 44.1
Supported DSD USB-C only 256, 128, 64
Bit depths (bit) 32, 24, 16
Frequency response (fi lter 1) 20Hz—20kHz ± 0.2dB
Signal/noise ratio (A-wtd, ref. 50W, 0dBFS) 110dB
SAÍDA DE HEADPHONE
Maximum output level (RMS) into 32Ω/300 Ohms 2.5V/5V
Load range 16 - 2k Ohms
|
