GERAL
Dimensão (L x A x P): 43.6 x 17.8 x 37.3 cm
Peso: 9.4 kg
AMPLIFICAÇÃO
Design do Amplificador: Direct Energy
Potência de Saída: Watts por Canal
- 80 W/ch (8 ohms, 20 Hz-20 kHz, THD 0.08 %, 2ch Driven, FTC);
- 170 W/ch (6 ohms, 1 kHz, THD 10 %, 1ch Driven);
Canais: 7
Potência de Saída: Watts por canal (1kHz,10%THD@6ohm 1ch Driven): 165 W/ch
CONECTIVIDADE
Entrada/Saída HDMI: 6 (Traseira)/2
Wi-Fi: Sim
Dual Band (5 GHz/2.4 GHz) Wi-Fi® Built-in
Entrada/Saída de Audio Digital: 2 (Optical 1, Coaxial 1)
Saída para Headphone: Sim
AM/FM Presets: AM/FM Tuner 40 Presets
Bluetooth: Sim (Versão: 4.2 + LE, Profile: A2DP 1.2/AVRCP 1.3, Codec: SBC/AAC)
USB Terminal: Frente e Traseira
Entrada/Saída de Audio Analogico: 2/0
Saída Pre-Amp: 0.2 ch.
Entradas Frontais A/V: USB / 3.5mm stereo mini jack
AUDIO
- Dolby Atmos®, Dolby Surround Upmixer;
- DTS:X®, DTS Neural:X® Upmixer;
- Reflex Optimizer;
- Dolby Atmos Height Virtualizer;
- DTS Virtual: X;
- Dolby® TrueHD, Dolby Digital Plus;
- DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS 96/24, DTS-ES, DTS-HD Express;
- DSD Disc (SACD) Playback via HDMI (2.8 MHz/2ch, 5.1ch);
- Digital Quad-Core 32-bit DSP (Cirrus Logic);
- 192 kHz/24-bit D/A Conversion for Hi-Res Audio;
- Enhanced Audio Return Channel (eARC) on HDMI OUT (MAIN);
- MCACC Auto Room Tuning: Phase Control | Subwoofer EQ;
- Advanced Sound Retriever (2ch);
Advanced Surround Modes: Classical, Unplugged, Entertainment Show, Drama, Advanced Game, Action, Rock/Pop, Sports, Extended Stereo, Mono Music, Front Stage Surround Advance
VIDEO
- Suporte a HDMI 2.1: (HDMI IN 1-3) com 8K, VRR (Variable Refresh Rate), ALLM (Auto Low Latency Mode), QFT (Quick Frame transport), DSC (Display Stream Compression), e QMS (Quick Media Switching) pass-through;
- Suporta HDR10+, HDR10, e HLG: 8K/60p (4:2:0/10-bit), 8K/30p (4:4:4/10-bit, 4:2:2/12-bit), 4K/120p (4:4:4/10-bit, 4:2:2/12-bit), 4K60p (4:4:4/12-bit) and BT.2020 color; Deep Color™ (36-bit), "x.v.Color", LipSync, e HDCP 2.3;
- Compatível com Dolby Vision;
- Upscaling Ultra HD: 4K para 8K, 1080p para 8K/4K;
PROCESSAMENTO DE VÍDEO
4K Ultra HD Pass-Through: Sim (HDR10, HLG e BT.2020 Wide Color Gamut Signal Pass-through)
Pronto para 3D: Sim
HDMI 36-bit Deep Color: Sim
4K Ultra HD Video Scaler: Ultra HD Upscaling
Canal de Retorno de Audio: Sim
Compatível com Dolby Vision: Sim
HDMI x.v. Color: Sim
Conversor de Video para HDMI: Sim
Super Resolução: Sim
TERMINAIS FRONTAIS
- Entrada USB
- Entrada para MCACC Setup
- Entrada para Audio 1 (Mini Stereo Jack)
- Saída para Headphones
OUTROS
- Funciona com Alexa;
- ChromeCast embutido;
- Funciona com AirPlay 2;
- Funciona com Amazon Music HD, Pandora®, Spotify, TIDAL, e Deezer
|
